System Controls

Automatic operation of the Complete System is controlled by PLC. The operation of the System is monitored by the System Operator via a panel mounted HMI. The ATS uses a combination of temperature and pressure drop across the system t ocontrol energy to the system, but also monitors Torr Gas make-up, system pressure and FlueGas Inlet and Outlet temperatures to control damper settings and fan speed.
Followings majorly constitute System Controls:

• HMI In-touch screens.

• PLC ladder logic program.

• Temperature Control Sensors

• Temperature Transmitters

• Gas Monitoring Devices

• Zero Speed Switches

• Pressure Transmitters

• Proximity Switches (Capacitive and Inductive)

• Plug Detectors

• Valves

• Nozzles

• Reactors, capacitors, motor terminators.
